Microtek SineWave UPS EB - FRONT PANEL - LCM-GRAPHIC LCD DISPLAY MODELS; LED Indications

7
CHARGE
BATTERY CAPACITY
LOAD
BATTERY
5
FUSE BLOWN
OVERLOAD
+
NORMAL
2
6
4
1
I.LED Indications
1. NORMAL - Mains ON.
2.BATTERY - Backup ON.
3.CHARGE - Battery Charging.
4.FUSE BLOWN.
5.OVERLOAD - at Output.
6.LOAD - Load Status on Backup Mode.
7.BATTERY CAPACITY / Status.
3
FRONT PANEL- LCM-GRAPHIC LCD DISPLAY MODELS
