Chapter 12 Serial Bus Trigger and Decode (Optional)
247
12.5 I2C Bus Trigger and Decode
For correctly decoding I2C bus data and making trigger stable, the bus configuration, trigger mode set and trigger
level need to be adjusted.
⚫ Bus configuration
Tap or to open the bus configuration menu, Bus configuration includes the serial clock (SCL) and
the serial data (SDA) corresponding to the channel settings. See Figure 12-22:
