r
c
l
10
10
5
5
0
20
15
30
40
balance
masters
MUTE
MUTE
Master Section
The BALANCE control provides a bus
trim for the left and right master signal
paths (prior to the insert point).
The stereo master MUTE switches cut
the post fader output signals but CAN
NOT be used as part of the console
snapshot system.
The mono master MUTE switch cuts
the post fader output signal fader but
CAN NOT be used as part of the
console snapshot system.
The two master FADERS control the
output levels of the main mix from
+10dB to off.
32
