SUPPLY VOLTAGE
100-240V~ 50-60Hz 375W
SUPPLY VOLTAGE
100-240V~ 50-60Hz 375W
FUSE T 6.3A 250V
FUSE T 6.3A 250V
psu 1
psu 2
MADE IN KIDDERMINSTER ENGLAND
C US
Front View
Rear View
Dimensions and Weights
Width: 482.6mm 19.00”
Height 2U: 88.50mm 3.48”
Depth: 372.0mm 14.65”
Depth (incl. connectors): 418.0mm 16.56”
Weight: 13.0Kg 28.6lbs
Specifications
Input Voltage Range: 100-240VAC
Maximum Output Power: 375W
o
Operating Temperature: 0-50 C
The POWER indicators
show the status of all rails
on the power supplies.
Power on / off switches
IEC sockets
Fuses
DC power connector
465.00mm 18.3”
76.20mm 3”
88.50mm 3.48”
482.60mm 19”
Measurements and Specifications
72
