There are two ways to place the end of drain hose:
•
• Position drain hose properly ,otherwise damage might result of water leakage.
• If drain hose is too long, do not force it into washing machine as it will cause
abnormal noises.
Do not kink or protract the drain hose.
Trough
Hose
Retainer
B
ind
Min.86cm
Max.100cm
Warning!
！
water trough
Under3m
Under 15cm
Min 8
6
c
m
.
1
0
0
cm
Max
.
1.For lower drain system
2.For upper drain system
1.Check if the legs are closely attached to
the cabinet. If not, please turn them to
their original positions tighten the nuts.
2.Check alignment of the product with a
spirit level and if required, correct.
3.Loosen the lock nut and turn the feet
until it closely contacts with the floor.
4.After being locked properly, press four
corners again to make sure that they has
been adjusted properly.
• The lock nuts on all four feet must be screwed tightly against the housing.
Levelling the washing machine
Warning!
！
Lock nut
foot
Raise
Lower
lockloosen
right
wrong
INSTALLATION
Installation of drain hose
1.Completely sleeve the drain hose over the sewer.
2.Fix and tighten it with a hoop.( As shown in the figure )
• Note: The drain hose of the machine with upper drain system has already been
assembled before leaving the factory. This picture is suitable for lower drain system.
Note!
