Part 2 - Outdoor Unit Engineering Data
Table 2-7.5: MDV-V56WDHN1(AtB) cooling capacity
Combination
(%) (Capacity
index)
Outdoor
temperature
(°C DB)
Indoor temperature(°C DB/WB)
DB:20.8,WB:14
DB:23.3,WB:16
DB:25.8,WB:18
DB:27,WB:19
DB:28.2,WB:20
DB:30.7,WB:22
DB:32,WB:24
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
TC
PI
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
kW
130%
-5.0
11.4
1.7
13.0
2.0
14.6
2.8
16.3
3.1
17.5
3.3
18.4
3.8
19.7
4.0
-2.0
11.4
1.7
13.0
2.0
14.6
2.9
16.3
3.1
17.5
3.4
18.4
3.9
19.7
4.0
0.0
11.4
1.7
13.0
2.0
14.6
2.9
16.3
3.1
17.5
3.4
18.4
3.9
19.7
4.1
2.0
11.4
1.8
13.0
2.1
14.6
3.0
16.3
3.3
17.5
3.6
18.4
4.1
19.7
4.3
4.0
11.4
1.8
13.0
2.1
14.6
3.0
16.3
3.3
17.5
3.6
18.4
4.1
19.7
4.3
6.0
11.4
1.8
13.0
2.2
14.6
3.1
16.3
3.3
17.5
3.6
18.4
4.2
19.7
4.3
8.0
11.4
1.8
13.0
2.2
14.6
3.1
16.3
3.3
17.5
3.6
18.4
4.2
19.7
4.3
10.0
11.4
1.9
13.0
2.2
14.6
3.1
16.3
3.4
17.5
3.7
18.4
4.2
19.7
4.3
12.0
11.4
1.9
13.0
2.2
14.6
3.1
16.3
3.4
17.5
3.7
18.4
4.3
19.7
4.4
14.0
11.4
1.9
13.0
2.2
14.6
3.1
16.3
3.4
17.5
3.7
18.4
4.3
19.7
4.4
16.0
11.4
1.9
13.0
2.2
14.6
3.2
16.3
3.5
17.5
3.8
18.4
4.3
19.7
4.5
18.0
11.4
1.9
13.0
2.2
14.6
3.2
16.3
3.5
17.5
3.8
18.4
4.4
19.7
4.5
20.0
11.4
1.9
13.0
2.3
14.6
3.2
16.3
3.5
17.5
3.8
18.4
4.4
19.7
4.5
21.0
11.4
1.9
13.0
2.3
14.6
3.2
16.3
3.5
17.5
3.8
18.4
4.4
19.7
4.5
23.0
11.4
2.1
13.0
2.4
14.6
3.4
16.3
3.8
17.5
4.1
18.4
4.7
19.7
4.8
25.0
11.4
2.2
13.0
2.6
14.6
3.7
16.3
4.0
17.5
4.3
18.4
5.0
19.7
5.2
27.0
11.4
2.3
13.0
2.7
14.6
3.9
16.3
4.2
17.5
4.6
18.4
5.3
19.7
5.5
29.0
11.4
2.5
13.0
2.9
14.6
4.1
16.3
4.5
17.5
4.8
18.4
5.6
19.7
5.8
31.0
11.4
2.6
13.0
3.0
14.6
4.3
16.3
4.7
17.5
5.1
18.4
5.9
19.7
6.1
33.0
11.4
2.7
13.0
3.2
14.6
4.5
16.3
4.9
17.5
5.4
18.4
6.2
19.7
6.4
35.0
11.4
2.8
13.0
3.3
14.6
4.7
16.3
5.2
17.5
5.6
18.4
6.5
19.7
6.7
37.0
11.0
2.8
12.6
3.3
14.1
4.7
15.7
5.2
16.9
5.6
17.8
6.5
19.0
6.7
39.0
10.6
2.8
12.1
3.4
13.6
4.7
15.2
5.2
16.3
5.6
17.1
6.5
18.3
6.7
41.0
10.2
2.8
11.7
3.4
13.1
4.7
14.6
5.2
15.7
5.6
16.5
6.5
17.7
6.7
43.0
9.8
2.9
11.2
3.4
12.6
4.7
14.0
5.2
15.1
5.6
15.9
6.5
17.0
6.7
46.0
9.3
2.9
10.7
3.4
12.0
4.7
13.3
5.2
14.4
5.6
15.1
6.5
16.1
6.7
48.0
8.2
3.0
9.4
3.5
10.5
4.9
11.7
5.4
12.6
5.9
13.2
6.8
14.2
7.0
50.0
7.1
2.8
8.1
3.3
9.1
4.6
10.1
5.1
10.8
5.5
11.4
6.4
12.2
6.5
52.0
5.9
2.6
6.8
3.1
7.6
4.4
8.4
4.8
9.1
5.2
9.5
6.0
10.2
6.1
54.0
4.8
2.3
5.5
2.7
6.1
3.8
6.8
4.1
7.3
4.5
7.7
5.2
8.2
5.3
120%
-5.0
11.2
1.7
12.8
1.9
14.4
2.8
16.0
3.0
17.2
3.3
18.1
3.8
19.3
3.9
-2.0
11.2
1.7
12.8
2.0
14.4
2.8
16.0
3.1
17.2
3.3
18.1
3.8
19.3
4.0
0.0
11.2
1.7
12.8
2.0
14.4
2.8
16.0
3.1
17.2
3.4
18.1
3.9
19.3
4.0
2.0
11.2
1.8
12.8
2.1
14.4
3.0
16.0
3.2
17.2
3.5
18.1
4.1
19.3
4.2
4.0
11.2
1.8
12.8
2.1
14.4
3.0
16.0
3.2
17.2
3.5
18.1
4.1
19.3
4.2
6.0
11.2
1.8
12.8
2.1
14.4
3.0
16.0
3.3
17.2
3.6
18.1
4.1
19.3
4.2
8.0
11.2
1.8
12.8
2.1
14.4
3.0
16.0
3.3
17.2
3.6
18.1
4.1
19.3
4.2
10.0
11.2
1.8
12.8
2.1
14.4
3.0
16.0
3.3
17.2
3.6
18.1
4.1
19.3
4.3
12.0
11.2
1.8
12.8
2.2
14.4
3.1
16.0
3.4
17.2
3.7
18.1
4.2
19.3
4.3
14.0
11.2
1.9
12.8
2.2
14.4
3.1
16.0
3.4
17.2
3.7
18.1
4.2
19.3
4.3
16.0
11.2
1.9
12.8
2.2
14.4
3.1
16.0
3.4
17.2
3.7
18.1
4.3
19.3
4.4
18.0
11.2
1.9
12.8
2.2
14.4
3.1
16.0
3.4
17.2
3.7
18.1
4.3
19.3
4.4
20.0
11.2
1.9
12.8
2.2
14.4
3.1
16.0
3.4
17.2
3.7
18.1
4.3
19.3
4.4
21.0
11.2
1.9
12.8
2.2
14.4
3.2
16.0
3.5
17.2
3.8
18.1
4.3
19.3
4.5
23.0
11.2
2.0
12.8
2.4
14.4
3.4
16.0
3.7
17.2
4.0
18.1
4.6
19.3
4.8
25.0
11.2
2.2
12.8
2.5
14.4
3.6
16.0
3.9
17.2
4.3
18.1
4.9
19.3
5.1
27.0
11.2
2.3
12.8
2.7
14.4
3.8
16.0
4.1
17.2
4.5
18.1
5.2
19.3
5.4
29.0
11.2
2.4
12.8
2.8
14.4
4.0
16.0
4.4
17.2
4.8
18.1
5.5
19.3
5.6
31.0
11.2
2.5
12.8
3.0
14.4
4.2
16.0
4.6
17.2
5.0
18.1
5.8
19.3
5.9
33.0
11.2
2.7
12.8
3.1
14.4
4.4
16.0
4.8
17.2
5.3
18.1
6.1
19.3
6.2
35.0
11.2
2.8
12.8
3.3
14.4
4.6
16.0
5.1
17.2
5.5
18.1
6.3
19.3
6.5
37.0
10.8
2.8
12.3
3.3
13.9
4.6
15.4
5.1
16.6
5.5
17.4
6.4
18.7
6.5
39.0
10.4
2.8
11.9
3.3
13.4
4.6
14.9
5.1
16.0
5.5
16.8
6.4
18.0
6.6
41.0
10.0
2.8
11.5
3.3
12.9
4.6
14.3
5.1
15.4
5.5
16.2
6.4
17.3
6.6
43.0
9.6
2.8
11.0
3.3
12.4
4.7
13.8
5.1
14.8
5.5
15.6
6.4
16.7
6.6
46.0
9.2
2.8
10.5
3.3
11.8
4.7
13.1
5.1
14.1
5.5
14.8
6.4
15.8
6.6
48.0
8.0
2.9
9.2
3.4
10.3
4.8
11.5
5.3
12.4
5.7
13.0
6.6
13.9
6.8
50.0
6.9
2.7
7.9
3.2
8.9
4.6
9.9
5.0
10.6
5.4
11.2
6.2
12.0
6.4
52.0
5.8
2.6
6.6
3.0
7.5
4.3
8.3
4.7
8.9
5.1
9.4
5.8
10.0
6.0
54.0
4.7
2.2
5.3
2.6
6.0
3.7
6.7
4.0
7.2
4.4
7.6
5.1
8.1
5.2
Abbreviations:
CR: Combination ratio
TC: Total capacity (kW)
PI: Power input (compressor + outdoor fan motor) (kW)
Notes:
1. Shaded cells indicate rating condition. Table continued on next page …
