Atom B Series VRF 50/60Hz
5
Part 1 –
General Information
2 External Appearance
2.1 Indoor Units
Table 1-2.1: Indoor unit appearance
One-way Cassette
Four-way Cassette
Q1
Q4
Compact Four-way Cassette
Wall-mounted
Q4C
G
Medium Static Pressure Duct
Ceiling and Floor
T2
DL
2.2 Outdoor Units
Table 1-2.2: Outdoor unit appearance
28kBtu/h
36/42/48/56kBtu/h
