Midea ATOM MDV-V48WDHN1 User Manual

Atom B Series VRF 50/60Hz
4
Midea Atom B Series VRF Engineering Data Book
1 Indoor and Outdoor Unit Capacities
1.1 Indoor Units
Table 1-1.1: Indoor unit abbreviation codes
Abbreviation code
Type
Q1
One-way Cassette
Q4C
Compact Four-way Cassette
Q4
Four-way Cassette
T2
Medium Static Pressure Duct
G
Wall-mounted
DL
Ceiling and Floor
Table 1-1.2: Indoor unit capacity range
Capacity
Capacity
index
Q1
Q4C
Q4
T2
G
DL
kBtu/h
kW
HP
6
1.8
0.6
6
6
—
—
—
—
7
2.2
0.8
7
7
7
—
7
7
9
2.8
1
9
9
9
9
9
9
12
3.6
1.25
12
12
12
12
12
12
12
15
4.5
1.6
15
15
15
15
15
15
15
18
5.6
2
18
18
—
18
18
18
18
24
7.1
2.5
24
24
—
24
24
24
24
28
8.0
3
28
—
—
28
28
28
28
32
9.0
3.2
32
—
—
32
32
32
32
36
10.0
3.6
36
—
—
36
—
—
36
40
11.2
4
40
—
—
40
40
—
40
48
14.0
5
48
—
—
48
48
—
48
56
16.0
6
56
—
—
56(DC)
56
—
Notes:
1. Atom series indoor units could connect to Atom series outdoor units.
1.2 Outdoor Units
Table 1-1.3: Outdoor unit capacity range
Capacity (kBtu/h)
Model Name
28
MDV-V28WDHN1(AtB)
36
MDV-V36WDHN1(AtB)
42
MDV-V42WDHN1(AtB)
48
MDV-V48WDHN1(AtB)
56
MDV-V56WDHN1(AtB)
Notes:
1. Atom series outdoor units could not be combined.

Midea ATOM MDV-V48WDHN1 Specifications

General

Brand	Midea
Model	ATOM MDV-V48WDHN1
Category	Air Conditioner
Language	English
