Midea Atom B Series VRF Engineering Data Book
3 Nomenclature
3.1 Indoor Units
MDV
-
D
09
Q4
/
N1
-
E
(At)
①
②
③
④
⑤
⑥
⑦
Legend
No.
Code
Remarks
1
MDV
Midea VRF
2
D
VRF indoor unit
3
09
Capacity index (the capacity in kBtu/h)
4
Q4
Indoor unit type
Q1: One-way Cassette
Q4C: Compact Four-way Cassette
Q4: Four-way Cassette
T2: Medium Static Pressure Duct
G: Wall Mounted
DL: Ceiling and Floor
5
N1
Refrigerant type (N1: R410A)
6
E
Design code
7
At
Atom series
3.2 Outdoor Units
MDV
-
V
28
W
D
H
N1
(AtB)
①
②
③
④
⑤
⑥
⑦
⑧
Legend
No.
Code
Remarks
1
MDV
Midea VRF
2
V
All DC inverter
3
28
Capacity index (the capacity in kBtu/h)
4
W
VRF outdoor unit
5
D
DC inverter compressor
6
H
Power supply
Omit: 1 phase, 220-240V, 50Hz
H: 1 phase, 220-240V, 50/60Hz
7
N1
Refrigerant type (N1: R410A)
8
AtB
Atom B series
