Blanc On-off DM16-01.01.07en
10 Service manual
Outdoor fan motor
Model
YKT-48-6-206
YKT-75-6-200L
Input W 93 75
Capacitor uF 3 3
Speed r/min 880 850
Outdoor coil
a.Number of rows 2 2
b.Tube pitch(a)x row pitch(b) mm 21x13.37 21x13.37
c.Fin spacing mm 1.4 1.5
d.Fin type (code) Hydrophilic aluminium Hydrophilic aluminium
e.Tube outside dia.and type mm Φ7,innergroove tube Φ7,innergroove tube
f.Coil length x height x width mm 755x504x26.74 740x630x13.37+760*630*13.37
g.Number of circuits 4 6
Outdoor noise level dB(A) 58 59
Outdoor unit
Dimension(W*D*H) mm 770x300x555 845x363x702
Packing (W*D*H) mm 900x345x585 965x395x755
Net/Gross weight Kg 34.9/37.3 49.2/52.4
Refrigerant type g R410A/1150g R410A/1750g
Design pressure MPa 4.2/1.5 4.2/1.5
Refrigerant piping
Liquid side/ Gas side mm(inch) Φ6.35/Φ12.7(1/4"/1/2") Φ9.52/Φ16(3/8"/5/8")
Max. refrigerant pipe length m 25 25
Max. difference in level m 10 10
Connection wiring 3x1.5+2x0.75(Optional) 4x1.0(Optional)
Plug type 1.5x3 -----
Remote Control RG70A/BGEF RG70A/BGEF
Operation temperature
℃
17-30 17-30
Room temperature
Indoor(cooling/ heating)
℃
17-32/0-30 17-32/0-30
Outdoor(cooling/heating)
℃
18-43/-7-24 18-43/-7-24
Application area (Cooling Standard) m2 24-35 32-47
