DM16-01.01.07en Blanc On-off
Service manual 9
Indoor model name MSMA1C-18HRN1 MSMA1D-24HRN1
Outdoor model name MOBA03-18HN1 MOCA02-24HN1
Power supply Ph-V-Hz 220-240V- 50Hz, 1Ph 220-240V- 50Hz, 1Ph
Cooling
Capacity
Btu/h 18000 24000
kW 5,28 7,03
Input W 1643 2503
Rated current A 7.1 10.9
EER W/W 3,21 2,81
Heating
Capacity
Btu/h 19000 26000
kW 5,57 7,62
Input W 1543 2374
Rated current A 6.7 10.3
COP W/W 3,61 3,21
Max. input consumption W 2400 4000
Max. current A 12 20
Starting current A / 54.5
Compressor
Model ASL211SV-C7LU1
PA280G2CS-4MTL
Type ROTARY ROTARY
Brand HITACHI GMCC
Capacity Btu/h 17299/- 27705/27824
Input W 1750/- 1910/1990
Rated current(RLA) A 4.75 8.8/8.05
Locked rotor Amp(LRA) A / 54.5
Thermal protector /
Thermal protector position INTERNAL INTERNAL
Capacitor uF 50 60
Refrigerant oil/oil charge ml ESTER OIL VG74/350 ESTER OIL VG74/850
Indoor fan motor
Model YKFG-25-4-6 YKFG-45-4-22
Input W 62 45
Capacitor uF 1.5 3
Speed(Hi/Mi/Lo) r/min 1180/1000/850 1200/1000/850
Indoor coil
a.Number of rows 2 2
b.Tube pitch(a)x row pitch(b) mm 21x13.37 21x13.37
c.Fin spacing mm 1.2 1.2
d.Fin type (code) Hydrophilic aluminium Hydrophilic aluminium
e.Tube outside dia.and type mm Φ7,innergroove tube Φ7,innergroove tube
f.Coil length x height x width mm 750x84x26.74+750x147x26.74 780x210x26.74+780x105x26.74
g.Number of circuits 3 4
Indoor air flow (Hi/Mi/Lo) m3/h 776/645/523 1010/810/659
Indoor noise level (Hi/Mi/Lo) dB(A) 42/38/35 47/41.5/37
Indoor unit
Dimension(W*D*H) mm 957x223x302 1040x235x327
Packing (W*D*H) mm 1035*305*380 1120*405*330
Net/Gross weight Kg 10.2/13.3 12.9/16.4
