Blanc On-off DM16-01.01.07en
8 Service manual
f.Coil length x height x
width
mm 510x253x23.2 510x253x23.2
595x78x23.2+595x117x2
3.2+595x78x23.2
g.Number of circuits 3 3 4
Indoor air flow (Hi/Mi/Lo) m3/h 436/381/300 456/380/306 564/436/342
Indoor noise level (Hi/Mi/Lo) dB(A) 36.0/34/30 39/34/29 42/38/36
Indoor unit
Dimension(W*D*H) mm
715*285*194 715*285*194
805x205x285
Packing (W*D*H) mm 765*270*345 765*270*345 870*285*360
Net/Gross weight Kg 7.1/9.3 7.1/9.3 8.0/10.3
Outdoor fan
motor
Model YKT-32-6-203L YKT-32-6-203L YKT-32-6-203L
Input W 72.5 72.5 72.5
Capacitor uF 2.5 2.5 2.5
Speed r/min 850 850 850
Outdoor coil
a.Number of rows 1 1 1
b.Tube pitch(a)x row
pitch(b)
mm
21x13.37 21x13.37
21×22
c.Fin spacing mm 1.4 1.4 1.2
d.Fin type (code) Hydrophilic aluminium Hydrophilic aluminium Hydrophilic aluminium
e.Tube outside dia.and
type
mm Φ7,innergroove tube Φ7,innergroove tube Φ7,innergroove tube
f.Coil length x height x
width
mm 685x508x13.37 685x508x13.37 744x504x22
g.Number of circuits 2 2 2
Outdoor noise level dB(A) 54 55 57
Outdoor unit
Dimension(W*D*H) mm 700x270x550 700x270x550 770x300x555
Packing (W*D*H) mm 815x325x615 815x325x615 900x345x585
Net/Gross weight Kg 23.1/25.2 25.3/27.6 29.5/32.0
Refrigerant type g R410A/520g R410A/590g R410A/740g
Design pressure MPa 4.2/1.5 4.2/1.5 4.2/1.5
Refrigerant
piping
Liquid side/ Gas side
mm(inc
h)
Φ6.35/Φ9.52(1/4"/3/8"
)
Φ6.35/Φ9.52(1/4"/3/8") Φ6.35/Φ12.7(1/4"/1/2")
Max. refrigerant pipe
length
m 20 20 20
Max. difference in level m 8 8 8
Connection wiring 5x1.0(Optional) 5x1.0(Optional) 3x1.5+2x0.75(Optional)
Plug type 3x1.5 / VDE 3x1.5 / VDE 3x1.5 / VDE
Remote Control RG70A/BGEF RG70A/BGEF RG70A/BGEF
Operation temperature
℃
17-30 17-30 17-30
Room
temperature
Indoor(cooling/ heating)
℃
17-32/0-30 17-32/0-30 17-32/0-30
Outdoor(cooling/heatin
g)
℃
18-43/-7-24 18-43/-7-24 18-43/-7-24
Application area (Cooling Standard) m2 10-15 12-18 16-23
