5. Review the “Electric requirements”.
BEFORE OPERATING OR TESTING, follow the grounding instructions in the “Grounding”.
U.S. Models:
Risk Of Electric Shock - All U.S. models are produced for a 3-WIRE SYSTEM
CONNECTION.
The dryer frame is grounded to the neutral conductor at the terminal block.
A 4-WIRE SYSTEM CONNECTION is required for new or remodeled construction, mobile
homes, or if local codes do not permit grounding through neutral conductor. If the 4-wire
system is used, the dryer frame cannot be grounded to the neutral conductor at the terminal
block. Refer to the “Electric requirements” section on 3-WIRE or 4-WIRE SYSTEM
CONNECTIONS.
6. [GAS MODELS ONLY]
Review the “Gas requirements” section on page 11. Remove the pipe thread protective cap.
Apply a pipe joint compound or about 1 ½” wraps of teflon tape over all threaded connections.
- The pipe joint compound must be resistant to the actions of any liquefied petroleum gas.
Connect the gas supply to your dryer. An additional fitting is required to connect the 3/4" (1.9cm)
female thread end of a flexible connector to the 3/8" (1cm) male threaded end on the dryer.
Securely tighten the gas line fitting over the threads.
Turn on the gas supply.
D r y e r
W a l l
D u c t
e x h a u s t
M a k e s u r e y o u r
d r y e r i s i n s t a l l e d
p r o p e r l y s o i t
e x h a u s t s a ir
e a s i l y .
4"
D u c t
T a p e
U s e a 4 i n c h . ( 1 0 . 2 c m )
d i a m e t e r r ig i d m e t a l
d u c t . T a p e a l l j o i n t s ,
i n c l u d i n g a t t h e d r y e r .
N e v e r u s e l i n t - t r a p p i n g
s c r e w s .
K e e p d u c t s a s
s t r a i g h t a s
p o s s i b l e .
C l e a n a l l o l d d u c t s
b e f o r e i n s t a l li n g y o u r
n e w d r y e r. B e s u r e t h e
v e n t f la p o p e n s a n d
c l o s e s f r e e ly . I n s p e c t
a n d c l e a n t h e e x h a u s t
s y s t e m a n n u a l l y .
D O N O T
r e s t r i c t y o u r
d r y e r w i t h a p o o r
e x h a u s t s y s t e m .
D O N O T u s e a p l a s t i c ,
t h i n f o i l , o r n o n - m e t a l
f le x i b l e d u c t .
D O N O T
u s e
u n n e c e s s a r i l y
l o n g d u c t s t h a t
h a v e m a n y
e l b o w s .
D O N O T u s e
d e n t e d o r c l o g g e d
d u c t s a n d v e n t .
