Midea CLADE67W User Manual

Service manual for Dryer Machine
-------------------------------------------------------------------------------------------------------------------------------------------------------
－ 26 －
4.5 Trouble shooting
No
Problem
What To Do
1
Will not start or
run
● All wires are hooked up to their corresponding terminals.
● Dryer is plugged in.
● Blown fuse or circuit breaker.
● Door switch functional…door closed.
● Star/Pause button rotary selector dial functional.
● Control Board operational.
● Belt off or broken and Belt Cut-off Switch operates.
● Drive motor functional.
● Check motor winding resistance: 2.88 ohms between pin #3 and 4,
3.5 ohms between pin #4 and 5.
2
Motor runs/
tumbler will not
turn
● Belt off or broken/ damaged.
● Idler tension spring too weak or stretched.
● Idler pulley jammed or stuck.
3
Runs a few
minutes and then
stops
● Lint buildup around drive motor.
● Low voltage present.
● Blower impeller blocked in blower housing.
● Drive motor – start switch contacts stuck closed.
4
Blows fuses or
trips circuit
breaker
● Is the belt connected well?
● Is the winding of the motor continuous?
(Rotor winding, stator winding, generator)
● Is the motor protector normal?
● If above points are not found, the PCB assembly is out of order.
Replace it.
5
Blows fuses or
trips circuit
breaker (Gas
model)
● During ignition the dryer will draw X amps. With the burner ON, the
dryer will draw X amps. If the dryer is drawing amperages above this,
then the house wiring, fuse box or circuit breaker is suspected to be at
fault.
● Igniter harness loose and shorted to base.
● Incorrect wiring or wire shorted to ground.
● Drive motor winding shorting to ground.
6
Will not heat
(motor runs)
Open heating element
● Hi-Limit trips easily or is open.
● Regulating thermostat trips easily or is open.
● Membrane switch open.
● Check thermistor.
7
Will not dry gas
Model poor gas
Ignition
When the dryer is operated on a heat setting, the igniter should be
energized and burner shall fire within 45 seconds at 120 VAC. The
failure of a component in this system will usually be indicated by one of
three symptoms.
8
The igniter does
not glow
If the igniter does not heat up, remove power and using an ohmmeter,
check the following:
