Midea CLADE67W User Manual

Service manual for Dryer Machine
-------------------------------------------------------------------------------------------------------------------------------------------------------
－ 31 －
4. Remove the back cover
4.1 Remove the screws
that is used to fix power
line;
4.2 Pull out the terminals;
4.3 Remove the screws on
the back cover;
4.4 Take down the back
cover;
4. Remove the back cover
(Gas model only)
4.1 Remove the screws
that is used to fix power
line;
4.2 Pull out the terminals;
4.3 Remove the screws on
the back cover;
4.4 Take down the back
cover;
5. Take down the tumble
assy
5.1 Remove the screws;
5.2 Take down the belt
from the Motor;
5.4 Hold the belt and take
down the tumble assy;

Midea CLADE67W Specifications

General

Brand	Midea
Model	CLADE67W
Category	Dryer
Language	English
