General Details
1.2 Description of SINGLESplit system components
12
13
2
A
B
5
11
6
9
7
1
8
10
3
4
Fig. 1
A Air inlet
B Air outlet
1 Wall mounting plate
2 Indoor unit
3 Ventilation louver
4 Filter
5 Outdoor unit
6 Flexible drainage hose
7 Electrical connection
8 Refrigerant piping
9 Outdoor unit power supply
10 Remote control
11 Remote control support
12 Display led CRISTALLO
13 Display led ESSENTIAL 2
l
WARNING
The images in this manual are provided for illustrative purposes only. The appearance of your device may
dier slightly from the illustrations shown here. Refer to the actual characteristics of the unit.
