Service Manual_2018-V2.0
16
6. Product specification
6.1 Electrical parameters
Applicable Models
HS-57LN
HS-65LN
Product Name
UR-BC50CM-ST
CE-BC50CM-ST
Product Code
22031010000502/
92031010Z00321/
92031010Z00061
/92031010Z00085/
92031010Z00088
/92031010Z00181
92031010Z00281
Item
Specification
Specification
Refrigerant
R600a
R600a
Compressor
FZ40C1J-U
SZ55C1J
Starter(PTC)
QP2-4R7
QP2-15
Overload protector(OLP)
DRB20T61A1
DRB12T61A1
Integrate PTC+OLP
None
None
Variable frequency driver board
None
None
Capacitor
None
None
Power filter
None
None
Winding resistance of
compressor wiring terminal
Rmc:13.72±7%Ω
Rsc:10.79±7%Ω
Rms=Rmc+Rsc
Rmc:40.25±7%Ω
Rsc:15.89±7%Ω
Rms=Rmc+Rsc
Winding resistance picture
The input power of compressor
50W
64.4W
Lights inside the refrigerator
Lights inside the refrigerating
chamber
None
None
Switch of the refrigerator door
None
None
6.2 Cooling temperature setting range
Compartment
The highest (
o
C)
Lowest (
o
C)
Freezing
-3
-10
Refrigerating
10
0
