Service Manual_2018-V2.0
20
8.3 Light system
Light of the refrigerating
There is a light switch on the side wall of the refrigerating
chamber.
Loosen the hook with small normal screwdriver and pull
out the switch until the wire connector revealss
8.4 Evaporator and Defrost system
8.5 Compressor case
Rear cover and compressor case
Rear cover and compressor case
Compressor and the cooling system pipe
1）Cut off the power, remove the goods in the
refrigerator, with the tape to make the door fixed firmly
and prevent the door dropping when the refrigerator
dumping.
Evaporator in freezing chamber
Evaporator in freezing chamber
