Midea CR034-RG36F Remote Control Manual

7 8
Indicators on LCD
Transmission Indicator
Temperature/Timer display
Fan speed display
Silence Display
Sleep Display
Mode display
ON/OFF display
This transmission indicator lights when remote
control transmits signals to the indoor unit.
Displays the current operation mode, including
AUTO ( ), COOL ( ), DRY ( ), HEAT ( )
(not applicable to cooling only models), FAN ( )
and back to AUTO ( ).
O O
Displays the temperature setting (17 C ~ 30 C).
When you set the operating mode to FAN, no
temperature setting is displayed. In the TIMER mode
the ON or OFF settings of the TIMER are displayed.
Displayed by pressing the ON/OFF button. Press
the ON/OFF button again to remove displayed icon.
Displays the selected fan speed, AUTO (no display)
and three fan speed levels " " (LOW) " " (MED)
" " (HIGH) can be indicated. The fan speed is
AUTO when the operating mode is AUTO or DRY.
Displayed when SILENCE function is activated.
Displayed under sleeping operation. Press the
SLEEP button again to remove displayed icon.
NOTE
All indicators shown in the figure are for the purpose
of clear presentation. But during the actual operation
only the relative functional signs are shown on the
display window.
Lock Display
Displayed when LOCK mode is activated.
FOLLOW ME Display
Displayed when FOLLOW ME function is activated.
F
auto cool dry heat fan
silence sleep follow me lock run
SET TEMP. TIMER ONOFF
How to use the Buttons
Cooling/Heating/Fan Operation
Ensure the unit is plugged in and power is
available.
1. Press the MODE button to select COOL,
HEAT or FAN mode.
2. Press the UP/DOWN buttons to set the
desired temperature. The temperature can
O O O
be set within a range of 17 C ~ 30 C in 1 C
increments.
3. Press the FAN SPEED button to select the
fan speed in four steps: AUTO, LOW, MED,
or HIGH.
4. Press the ON/OFF button to start the air
conditioner.
In FAN mode, the set temperature is not displayed
in the remote control and it is not possible to control
the room temperature. In this case, only steps 1, 3
and 4 may be performed.
NOTE
Auto Operation
Ensure the unit is plugged in and power is
available. The OPERATION indicator on the
display panel of the indoor unit starts flashing.
1. Press the MODE button to select AUTO.
2. Press the UP/DOWN button to set the
desired temperature. The temperature can
O O O
be set within a range of 17 C ~ 30 C in 1 C
increments.
3. Press the ON/OFF button to start the air
conditioner.
1. In the AUTO mode, the air conditioner can logically
choose the mode of Cooling, Fan, and Heating
by sensing the difference between the actual
ambient room temperature and the set temperature
on the remote control.
2. In the AUTO mode, you can not switch the fan
speed. It has already been automatically controlled.
3. If the AUTO mode is not comfortable for you, the
desired mode can be selected manually.
NOTE
3
1
2
4
1
2
3
2
2
TURBO
SELF
CLEAN
SLEEP
FRESH
SILENCE
FP
TIMER
ON/OF F
INTELL IGENT
EYE
LOCK
RESET
LED
FOLLOW
ME
FAN
SPEED
SWING
MODE
TEMP
ON/OFF
ON/OFF
SWING
TURBO
SELF
CLEAN
SLEEP
FRESH
SILENCE
FP
TIMER
ON/OF F
INTELL IGENT
EYE
LOCK
RESET
LED
FOLLOW
ME
FAN
SPEED
SWING
MODE
TEMP
SWING
F

Midea CR034-RG36F Specifications

General

Brand	Midea
Model	CR034-RG36F
Category	Air Conditioner
Language	English
