Midea CTBU-09HWFN1-M

140
1) After remove the panel
plate following procedure
1, remove the hex nut
fixing the fan and then
remove the fan.
2) Unfix the hooks and
then open the electronic
control box cover.
3) Disconnect the
○
1
○
2
T3,T4,T5 sensor wire
Motor wire
Electronic expansion valve
Compressor wire
4 way valve wire
Electric pipe heater and Crankcase electric heater
