Page 25
Operating
Instructions
(With Remote)
NOTE
When setting the TIMER ON or TIMER OFF functions,
up to 10 hours, the time will increase in 30 minute
increments with each press. After 10 hours and up to
24, it will increase in 1 hour increments. The timer will
revert to zero after 24 hours.
You can turn off either function by setting its timer to
“0.0h“.
3. Wait 2 seconds, then the TIMER OFF function will be
activated. The digital display on your remote control will
then return to the temperature display.
T i m e r on
Continue
to press
or
until desired
time is
reached.
ON/OFF
MODE
SHORT
CUT
TIMER ON
TEMP
sec
4
ON/OFF
MODE
SHORT
CUT
TIMER ON
TEMP
sec
8
1
X12
2
5
X16
6
3
7
Setting both TIMER ON and
TIMER OFF at the sa me time
Keep in mind that the time
periods you set for both
functions refer to hours after the
current time. For example, say
that the current time is 1:00 PM,
and you want the unit to turn on
automatically at 7:00 PM. You
want it to operate for 2 hours,
then automatically turn
off at 9:00 PM.
Do the following (side figure):
Example: Setting the unit to turn on after 6 hours, operate for 2 hours, then turn off (see
the figure below)
Timer On
Timer Off
Timer is set
To turn ON
6 hours from
current time
Timer is set
To turn OFF
8 hours from
current time
Current
Time 1PM
2PM 3PM
4PM 5PM
6PM 7PM 8PM 9PM
Unit turns
ON
Unit turns
OFF
6 hours later
8 hours later
Timer
Stars
Your remote display
mode
fan
fav.
temperature
sleep swing follow me LED
To Next Page
