Midea F Series

16
(4). PH-KC25/N1-F1F((C1)(MWF1-09CMN1-NC1)
POWER
BROWN OR
BLACK (L)
HIGH COOL
HIGH FAN
OFF
LOW FAN
LOW COOL
0
4
2
1
3
MAIN SWITCH
M
~
M
~
COMP
THERMOSTAT
G&Y OR GREEN
BLUE OR WHITE (N)
E
RED
RED
YELLOW
BLUE
BROWN
BLACK
FAN
CAP
RED
BLUE
E
BLACK
CAP
R
S
C
L
C
E
MID FAN
MID COOL
M
~
BLACK
BLACK
LOUVER MOTOR
WHITE
1
1b
1a
RED
LOUVER SWITCH
A
202021490169
