Service Manual_2018-V1.0
19
1） pull out the upper part on the rollover beam to
separate the upper part from the door;
2） pull out the whole rollover beam to seperature
the lower part from the door;
3） Unplug the wire terminal, remove the rollover
beam, reverse the operation to complete the
installation.
Disassembly and assembly of freezer door and annex
1) open the refrigerator doors, and pull the freezer
drawer outwards to the end, then incline the inside
drawer liner at an angle and take it out;
2）With the assistive tooling, press down left and
right bottom of bracket;
To Next Page
