Installation
Page 36
1. Installation Overview
Installation Order
Select Installation Location
Attach Mounting Plate Drill Wall Hole
Determine Wall Hole Position
1 2
3 4
12cm
(4.75in)
2.3m (90.55in)
12cm
(4.75in)
15cm (5.9in)
