Specifications
Page 6
Outdoor fan
motor
Model
YKT-21-6-10L YKT-48-6-206-6 YKT-63-6-200L
Input W
55.5 103.8 136.0
Insulation class B B B
IP rating IPX4 IPX4 IPX4
Capacitor uF 1.5 3 3
Capacitor class P2 P2 P2
Speed r/min
870 880 810/720
Outdoor coil
Number of rows
1.0 1.0 1.0
Tube pitch(a)x row
pitch(b)
mm
14.5x12.56 19.5x11.6 19.5x11.6
Fin spacing mm
1.2 1.2 1.2
Fin type (code)
Unhydrophilic aluminium Unhydrophilic aluminium Unhydrophilic aluminium
Tube outside dia.and
type
mm
Ф5,Inner groove tube Ф5,Inner groove tube Ф5,Inner groove tube
Coil length x height x
width
mm
675x406x12.56 760x507x11.6 778x663x11.6
Number of circuits
2 2 3
Outdoor air flow m3/h
1295 2091 2884
Outdoor sound pressure level dB(A)
53 56.5 60.0
Outdoor unit
Dimension(W*D*H) mm
681x285x434 770x300x555 845x363x702
Packing (W*D*H) mm
795x345x505 900x348x625 965x395x775
Net/Gross weight Kg
23.7/25.6 33.4/35.8 42.3/45.3
Refrigerant
Type
R410A R410A R410A
Charged quantity Kg
0.46 0.56 0.91
Design pressure MPa
4.2/1.5 4.2/1.5 4.2/1.5
Refrigerant
piping
Liquid side/ Gas side mm(inch)
Φ6.35/Φ9.52(1/4"/3/8") Φ6.35/Φ12.7(1/4"/1/2") Φ9.52/Φ15.9(3/8”/5/8”)
Max. refrigerant pipe
length
m
20 25 25
Max. difference in
level
m
8 10 10
Connection wiring
1.5x3Core 2.5x3Core 1.0x4Core
Plug type
16#x3/SP008 1.5x3/no-plug 1.5x3/no-plug
Thermostat type
Remote Control Remote Control Remote Control
Operation temperature
17-30 17-30 17-30
Ambient tem-
perature
Indoor(cooling/ heat-
ing)
°C
17-32/- 17-32/- 17-32/-
Outdoor(cooling/heat-
ing)
°C
18-43/- 18-43/- 18-43/-
Qty’per 20’ /40’ /40’HQ
124/267/300 86/180/208 64/136/146
Notes:
1) Capacities are based on the following conditions:
Cooling(T1): - Indoor Temperature 27°C(80.6°F) DB /19 °C(66.2°F) WB
-Outdoor Temperature 35 °C(95°F) DB /24 °C(75.2°F) WB
-Interconnecting Piping Length 5m
- Level Difference of Zero.
2) Capacities are Net Capacities.
3) Due to our policy of innovation some specifications may be changed without notification.
