Midea FZ10-21CR

维修手册 Service Manual, 2017 v1.0
6 / 12
2.7 电源板拆卸 Disassembly of power panel
用螺丝刀松开防火盒螺钉，拿出电源板
Using a screwdriver, loosen the fireproof box
screw and remove the power board.
2.8 出风口框、装饰件拆卸 Disassembly of air outlet frame and decorative pieces
1、 将出风口框从前壳上拆下。
2、 将装饰件从出风口框上拆下。
1. Remove the air outlet frame from the front
shell.
2. Remove the decorative pieces from the air
outlet frame.
3. 整机的安装 Function and operation
