MCAC-CTSM-2018-1 Flooded type water cooled screw chiller (MIC)
47
Figure 6.10
Dialog box like figure 6.11 appears if user inputs wrong password. Press Confirm to return to the input
interface, then input password again.
Figure 6.11
User parameter setting-temperature setting
Input the password （40828）and enter the page as figure 6.12 shows below:
Figure 6.12
“MAX” at the top left of setting window is upper limit of parameter setting, and “MIN” is lower limit of
parameter setting (out of range is not accepted). Press Enter button to confirm input. Press CLR
button to cancel input. The keyboard for number input will disappear.
Noun explanation
