WARNING
!
Make sure that the drain holes is facing down during installation
Only authorised personnel can install a side diverter. The side diverter incorporates the following
mechanical means to prevent incorrect installation, please pay attention:
1. Two screws are installed on the left side of the mounting bracket, and one screw is installed
on theright side, as per image above. Note the position of the left screws are not in a horizontal line.
2. The mounting bracket for the side diverter has a locating tab on the lower right, as per image
above, to ensure only this side is fitted to the right side exhaust opening.
