Left side of flue gas outlet
Left side of flue gas outlet
Right side of flue gas outlet
Right side of flue gas outlet
A
A
B
B
C
C
29
The side diverter can be configured to have the flue gas outlet on either the left or the right
side.To reverse the direction complete the following (as shown in the figure below):
1.Remove the fixed screw
2.Swap the A & C module positions
3.Refix the corresponding screws
