Midea M2OD-16HFN1-Q - Page 15

DM15-01.01.11-01en Service manual
Multi DC inverter R410A. Outdoor unit 15
Outdoor Model M50D-42HFN1-Q
Power supply V-ph-Hz Single Double Three FOUR FIVE
220-240V- 50Hz, 1Ph
Cooling
Capacity kW
2,05-5,28 4,10-8,21 6,15-10,55 8,21-11,72
12,31
Input W
680-1800 1400-2780 2100-3450 2700-3700 3830
Rated current A
3.0-8.0 6.2-11.8 9.0-15.0 11.6-16.0 17,5
EER
/ / / / 3,21
Heating
Capacity kW
2,05-5,28 4,10-8,21 6,15-10,55 8,21-11,72
12,31
Input W
680-1800 1400-2680 1995-3330 2580-3570 3410
Rated current A
3.0-8.0 6.2-11.3 8.5-14.5 11.1-15.8 15,6
COP
/ / / / 3,61
Max. input consumption W 5600
Max. input current A 25
Compressor
Model MNB36FAAMC-L
Type Twin-rotary
Brand MITSUBISHI
Capacity Btu/h 40603
Input W 3520
Rated current(RLA) A 13.4
Locked rotor Amp(LRA) A -----
Thermal protector position Internal
Capacitor μF -----
Refrigerant oil ml 1400
Outdoor fan
motor
Model WZDK180-38G
Qty 1
Output W 180
Capacitor μF - -
Speed(Hi/Med/Lo) r/min 800
Outdoor coil
Number of rows 3
Tube pitch(a)* row pitch(b) mm 21x13.37
Fin spacing mm 1.4
Fin type Hydrophilic aluminium
Tube outside dia.and type mm Φ7,inner groove tube
Coil length * height * width mm 891x903x40.11
Number of circuits 8
Outdoor air flow m3/h 5400
Outdoor sound pressure level dB(A) 66
Outdoor sound power level dB(A) 72
Throttle type Capillary
Outdoor unit
Dimension(WxDxH) mm 990x345x965
Packing(WxDxH) mm 1120x435x1100
Net/Gross weight kg 83.5/93
Refrigerant
Type R410A
GWP 2088
Charged quantity Kg 3.5
Design pressure MPa 4.2/1.5
Refrigerant
piping
Liquid side/ Gas side mm(inch) 5 x Φ6.35/Φ9.52(1/4"/3/8")
Max. length for all rooms m 75
Max. length for one indoor unit m 30
