DM15-01.01.11-01en Service manual
Multi DC inverter R410A. Outdoor unit 7
Outdoor Model M3OD-21HFN1-Q M3OD-26HFN1-Q
Power supply V-ph-Hz 220-240V- 50Hz, 1Ph 220-240V- 50Hz, 1Ph
Single Double Three Single Double Three
Cooling
Capacity kW 2,05-3,52 4,10-5,28 6,45 2,05-3,52 4,10-5,28 7,62
Input W 1000-1300 1500-1780 1970 / / 2370
Rated current A 4.4-5.7 6.5-7.7 8,83 / / 10,6
EER / / 3,27 / / 3,21
Heating
Capacity kW 2,64-4,10 4,98-5,86 6,57 2,64-4,10 4,98-5,86 6,74
Input W 900-1200 1400-1630 1780 / / 1840
Rated current A 4.0-5.3 6.1-7.1 7,98 / / 8,2
COP / / 3,69 / / 3,67
Max. input consumption W 3300 3300
Max. input current A 15 15
Compressor
Model DA150S1C-20FZ DA150S1C-20FZ
Type Twin-rotary Twin-rotary
Brand GMCC GMCC
Capacity Btu/h 15286 15286
Input W 1150 1150
Rated current(RLA) A 9.7 9.7
Locked rotor Amp(LRA) A / /
Thermal protector position EXTERNAL EXTERNAL
Capacitor μF / /
Refrigerant oil ml ESTER OIL VG74/500 ESTER OIL VG74/500
Outdoor fan
motor
Model WZDK50-38G WZDK50-38G
Qty 1 1
Output W 50 50
Capacitor μF / /
Speed(Hi/Med/Lo) r/min 750 750
Outdoor coil
Number of rows 2 2
Tube pitch(a)* row pitch(b) mm 25.4x22 25.4x22
Fin spacing mm 1.4 1,4
Fin type Hydrophilic aluminium Hydrophilic aluminium
Tube outside dia.and type mm Φ9.52,innergroove tube Ф9.52, inner groove tube
Coil length * height * width mm 766x660x44 766x660x44
Number of circuits 4 4
Outdoor air flow m3/h 2700 2700
Outdoor sound pressure level dB(A) 58 58
Outdoor sound power level dB(A) 64 68
Throttle type Capillary+EXV Capillary+EXV
Outdoor unit
Dimension(WxDxH) mm 845x320x700 845x320x700
Packing(WxDxH) mm 965x395x755 965x395x755
Net/Gross weight kg 50 / 54 50/54
Refrigerant
Type R410A R410A
GWP 2088 2088
Charged quantity Kg 2,1 2.1
Design pressure MPa 4.2/1.5 4.2/1.5
Refrigerant
piping
Liquid side/ Gas side mm(inch) 3 x Φ6.35/Φ9.52(1/4"/3/8") 3 x Φ6.35/Φ9.52(1/4"/3/8")
Max. length for all rooms m 45 45
Max. length for one indoor
unit
m 25 25
