Midea M2OF-18HFN1-Q User Manual

DM16-01.01.11-01en Service manual
Multi DC inverter R410A. Outdoor unit 5
3. Specification
Outdoor Model M2OE-14HFN1-Q M2OF-18HFN1-Q
Indoor unit combination Single Double Single Double
Power supply V-ph-Hz 220-240V- 50Hz, 1Ph 220-240V- 50Hz, 1Ph
Cooling
Capacity Btu/h
7000-14000 14000 7000-18000 18000
Input W 660-1250 1200 650-1600 1643
Rated current A 2.9-5.4 5,2 2.8-7.0 7,1
EER W/W / 3,30 / 3,21
Heating
Capacity Btu/h
8000-15000 15000 7000-19000 19000
Input W 620-1280 1160 542-1596 1543
Rated current A 2.7-5.6 5 2.3-6.9 6,7
COP W/W / 3,80 / 3,61
Max. input consumption W 2000 2600
Max. input current A 11 14
Compressor
Model
ASN108D22UEZ ASM135D23UFZ
Type ROTARY ROTARY
Brand GMCC GMCC
Capacity Btu/h 10987 13836
Input W 825 1035
Rated current(RLA) A 5,8 7.32
Locked rotor Amp(LRA) A / ----
Thermal protector position / ----
Capacitor μF / ----
Refrigerant oil ml ESTER OIL VG74 370 ESTER OIL VG74/450
Outdoor fan
motor
New Model ZKFN-40-8-1L ZKFN-40-8-1L
Model
Qty 40(Output) 40(Output)
Output W / /
Capacitor μF / /
Speed(Hi/Med/Lo) r/min 810 810
Outdoor coil
Number of rows
1 2
Tube pitch(a)* row pitch(b) mm 21x13.37 25.4x22
Fin spacing mm 1.2 1.4
Fin type Hydrophilic aluminium Hydrophilic aluminium
Tube outside dia.and type mm Φ7,innergroove tube Φ9.52,innergroove tube
Coil length * height * width mm 870x504x13.37 860x508x44
Number of circuits 2 4
Outdoor air flow m3/h 2100 2100
Outdoor sound pressure level dB(A) 54 56.5
Throttle type Capillary+EXV Capillary+EXV
Outdoor unit
Dimension(WxDxH) mm
800x333x554 800x333x554
Packing(WxDxH) mm 920x390x615 920x390x615
Net/Gross weight kg 30.5/33.5 36/39
Refrigerant
Type
R410A R410A
GWP 2088 2088
Charged quantity Kg 1.25 1.7
Design pressure MPa 4.2/1.5 4.2/1.5
Refrigerant
piping
Liquid side/ Gas side mm(inch)
2 x Φ6.35/Φ9.52(1/4"/3/8") 2 x Φ6.35/Φ9.52(1/4"/3/8")
Max. length for all rooms m 30 30
Max. length for one indoor unit m 20 20
Max. height difference
between indoor and
outdoor unit
OU higher
than IU
m
10 10
OU lower
than IU
m
15 15
Max. height difference between indoor
units
m
10 10
Ambient
temperature
Cooling
Ԩ
-15-50 -15-50
Heating
Ԩ
-15-24 -15-24
1.The above design and specifications are subject to change without prior notice for product improvement.
2.The values given in the table for the noise level reflect the levels in hemi-anechoic rooms.

Midea M2OF-18HFN1-Q Specifications
