DM16-01.01.11-01en Service manual
Multi DC inverter R410A. Outdoor unit 9
Outdoor Model M5OE-42HFN1-Q
Indoor unit combination Single Double Three FOUR Five
Power supply V-ph-Hz 220-240V- 50Hz, 1Ph
Cooling
Capacity Btu/h 7000-18000 14000-28000 21000-36000 28000-40000 42000
Input W 680-1800 1400-2780 2100-3450 2700-3700 3822
Rated current A 3.0-8.0 6.2-11.8 9.0-15.0 11.6-16.0 16,6
EER W/W / / / / 3,22
Heating
Capacity Btu/h 7000-18000 14000-28000 21000-36000 28000-40000 42000
Input W 680-1800 1400-2680 1995-3330 2580-3570 3372
Rated current A 3.0-8.0 6.2-11.3 8.5-14.5 11.1-15.8 14,7
COP W/W / / / / 3,65
Max. input consumption W 4700
Max. input current A 22
Compressor
Model ATF310D43UMT
Type ROTARY
Brand GMCC
Capacity Btu/h 32380
Input W 2600
Rated current(RLA) A 5,1
Locked rotor Amp(LRA) A -----
Thermal protector position INTERNAL
Capacitor μF -----
Refrigerant oil ml PQE(VG74)/1000
Outdoor fan
motor
New Model ZKFN-120-8-2
Model WZDK120-38G-W
Qty 1
Output W 120(Output)
Capacitor μF -----
Speed(Hi/Med/Lo) r/min 900
Outdoor coil
Number of rows 2,6
Tube pitch(a)* row pitch(b) mm 25.4x22
Fin spacing mm 1.3
Fin type Hydrophilic aluminium
Tube outside dia.and type mm Φ9.52,innergroove tube
Coil length * height * width mm 978x762x44+580x762x22
Number of circuits 4
Outdoor air flow m3/h 5500
Outdoor sound pressure level dB(A) 62
Throttle type Capillary+EXV
Outdoor unit
Dimension(WxDxH) mm 946x410x810
Packing(WxDxH) mm 1090x500x865
Net/Gross weight kg 76/81
Refrigerant
Type R410A
GWP 2088
Charged quantity Kg 3.6
Design pressure MPa 4.2/1.5
Refrigerant
piping
Liquid side/ Gas side mm(inch) 5 x Φ6.35/4x Φ9.52+1xΦ12.7(5x1/4"/4x3/8"+1x1/2")
Max. length for all rooms m 75
Max. length for one indoor unit m 30
Max. height difference
between indoor and
outdoor unit
OU higher
than IU
m 10
OU lower
than IU
m 15
Max. height difference between indoor
units
m 10
Ambient
temperature
Cooling ℃ -15-50
Heating
℃
-15-24
1.The above design and specifications are subject to change without prior notice for product improvement.
2.The values given in the table for the noise level reflect the levels in hemi-anechoic rooms.
