Service manual for portable washer Midea America Company
-------------------------------------------------------------------------------------------------------------------------------------------------------
－ 26 －
Take care the slots fixing the Control.
After re-connected, clamp
the cap with the plier.
Make sure the connection is
right before packing with the
original bag.
6
Remove the
Pump
Remove the clamps
connecting the drainage pipe
with pump with plier.
Remove the screws fixing the
pump with Phillips
screwdriver.
7
Remove the
Control panel
Remove the two plastics
sheet covering the screws
which fixing the control panel
with knife.
Remove the screws with
Phillips screwdriver.
Remove the control panel.
