7. SPARE PARTS
No. Part Name Quantity
1.1 Outer Tub Cover 1
1.3 Impeller Screw 1
1.4 T.L.Washer 1
1.5 Impeller And Connect Sleeve 1
1.6 Special Washer (Up) 1
1.7 Suspend System 1
1.8 Up Drain Hose Assembly 1
1.9 Middle Hose Assembly 1
1.10 Cabinet Base Assembly 1
1.11 Back Cover Plate 1
1.12 Converter 1
1.13 Water Inlet Hose Assembly 2
1.14 Air Pipe 1
1.15 Clip Spring 2
1.16 Rear Cover 1
1.17 Handle 2
1.18 Cabinet Subassembly 1
1.19 Capacitor Assembly 1
1.20 Capacitor Cover 1
1.21 Wire Connector 5
1.22 Wire Connector 1
1.23 Power Cord 1
1.24 Drain Pump 1
1.25 Hole Cover 2
1.26 Stationary Foot 1
1.27 Adjustable Foot 1
2.1 Balance Ring Assembly 1
2.2 Filtering Bag Assembly 1
2.3 Spray Cover 1
2.4 Tub Bottom Base 1
2.5 Coupling Plate 1
3.1 Cover Assembly 1
3.2 Cover Pin 2
3.3 Twist Spring 1
3.4 Water Inlet Valve Cover Assembly 1
3.5 Back Control Panel Assembly 1
3.6 Impact Switch 1
3.7 Water Inlet Valve 1
