Operating
Instructions
(With Remote)
NOTE
When setting the TIMER ON or TIMER OFF functions,
up to 10 hours, the time will increase in 30 minute
increments with each press. After 10 hours and up to
24, it will increase in 1 hour increments. The timer will
revert to zero after 24 hours.
You can turn off either function by setting the timer to
“0.0h“.
3. Wait 2 seconds, then the TIMER OFF function will be
activated. The digital display on your remote control will
then return to the temperature display.
ON/OF F
TEMP
SHORT
CU T
TIMER
ON
TIMER
OF F
MODE
FAN
SLEEP
LED
Timer on
FOLLOW
ME
Continue
to press
TIMER ON
or
TIMER OFF
until desired
time is
reached.
ON/OFF
MODE
SHORT
CUT
TIMER ON
TEMP
sec
4
ON/OFF
MODE
SHORT
CUT
TIMER ON
TEMP
sec
8
1
TIMER ON
X12
2
TIMER ON
5
TIMER OFF
X16
6
TIMER OFF
3
7
Setting both TIMER ON and
TIMER OFF at the same time
Keep in mind that the time
periods you set for both
functions refer to hours after
the current time.
For example, say that the
current time is 1:00 PM, and
you want the unit to turn on
automatically at 7:00 PM and
want it to operate for 2 hours,
then automatically turn off at
9:00 PM.
Follow the illustration to the
left:
Timer On
Timer Off
Timer is set
To turn ON
6 hours from
current time
Timer is set
To turn OFF
8 hours from
current time
Current
Time 1PM
2PM 3PM
4PM 5PM
6PM 7PM 8PM 9PM
Unit turns
ON
Unit turns
OFF
6 hours later
8 hours later
Timer
Starts
Example: Setting the unit to turn on after 6 hours, operate for 2 hours, and then
turn off (see the figure below)
Your remote display
Timer Functions (cont.)
