Aqua Tempo Super II
18 201902
Midea Aqua Tempo Super II Engineering Data Book
Table 2-1.3: Pump specifications
Pump model name
YKB-650-2-1 YKB-1500-2-1
Corresponding unit model name MC-SU30M-RN1L MC-SU60M-RN1L
Power supply 380-415 V/3Ph/Hz 380-415 V/3Ph/Hz
Rated power 0.65 KW 1.5 KW
Rated current 1.6-1.8A 3.15A
Rated water flow 4.7 m3/h 10m3/h
Rated pump head 22.8 m 27.8 m
Rated speed 2770-2820 r/min 2890-2910 r/min
Max operating temperature 55 °C 55 °C
Max operating pressure 1M Pa 1M Pa
Power factor 0.82-0.72 0.87-0.82
Efficiency 72.9%-73.9% 84.2%-84.9%
Started current 580-620 % of Rated current 850-930 % of Rated current
Resistance class IP55 IP55
Insulation class F F
Net/Gross weight 11.9 kg/14.4 kg 32.6 kg/35.1 kg
