Aqua Tempo Super II Series DC Inverter Air-cooled chiller unit (50Hz) MCAC-ATSM-201704
65
19.3 Wired controller specifications
Model KJRM-120H/BMWKO-E
Power Supply Voltage AC 10.5 V
Wiring size 0.75mm
Performance Features
1. Newly designed dot-matrix display.
2. Operating mode: cooling mode, heating mode, and water pump mode.
3. 3-level users: user, project and service
4. Auto-restart function
5. Address setting function
6. combination function
19.4 Menu Operations
19.4.1 Unlocking/Locking Operation
When the wired controller is locked, press and hold the "UNLOCK" button for 2s to unlock it, when " " is
not displayed; in the unlocked status, press and hold the "UNLOCK" button for 2s to lock it, when " " is
displayed and the wired controller cannot be operated; when there is no operation for continuous 60s on any
page, the wired controller returns to the home page and is locked automatically, and the locking icon is
displayed.
