DM17-01.01.08en Light Commercial R410A on-off
12
Specification
2.
Indoor model MCA3-12HRN1-Q1 MCA3-18HRN1-Q1
Outdoor model MOBA30U-12HN1-Q MOBA30U-18HN1-Q
Power supply V-ph-Hz 220~240-1-50 220~240-1-50
Cooling
Capacity
Btu/h 12500 18300
kW 3,66 5,36
Input W 1350 1980
Current A 6 8,78
EER W/W 2,71 2,71
Heating
Capacity
Btu/h 13000 19000
kW 3,81 5,57
Input W 1320 1720
Current A 5,9 7,63
COP W/W 2,89 3,24
Indoor fan
motor
Model YKT-17-6-6 YKT-27-4-6
Qty 1 1
Input W 40.5/35.3/31.4 78/71/51/39
Capacitor uF 1.5UF/450V 2UF/450V
Speed(Hi/Med/Lo) r/min 640/540/440 890/850/685/583
Indoor coil
Number of rows
1
2
Tube pitch(a)x row pitch(b) mm 21x13.37 21x13.37
Fin spacing mm
1,3
1,3
Fin type Hydrophilic aluminium Hydrophilic aluminium
Tube outside dia.and type mm Φ7,innergroove tube Φ7,innergroove tube
Coil length x height x width mm
1380x210x13.37
1360x210x26.74
Number of circuits
3
4
Indoor air flow (Hi/Mid/Lo) m
/h 650/550/430 810/650/530
Indoor noise level (sound pressure) (Hi/Mid/Lo) dB(A) 42/38/36 48/41/36
Throttle type / /
Indoor unit
Dimension (WxDxH)(body) mm 570x570x260 570x570x260
Packing (WxDxH)(body) mm 655x655x290 655x655x290
Dimension (WxDxH)(panel) mm 647x647x50 647x647x50
Packing (WxDxH)(panel) mm 715x715x123 715x715x123
Net/Gross weight(body) kg 16.3/19.1 16.5/19
Net/Gross weight(panel) kg 2.5/4.5 2.5/4.5
Design pressure MPa 4.2/1.5 4.2/1.5
Drainage water pipe diameter mm ODΦ25 ODΦ25
Refrigerant
piping
Liquid side/Gas side mm Φ6.35/Φ12.7(1/4"/1/2") Φ6.35/Φ12.7(1/4"/1/2")
Controller RG36C/BG(C)E RG36C/BG(C)E
Operation temperature ℃ 17~30 17~30
Room
temperature
Cooling
℃
17~32 17~32
Heating
℃
0~30 0~30
Remarks:
1.The above design and specifications are subject to change without prior notice for product improvement.
