Midea MCA3-12HRN1-Q1 User Manual

Light Commercial R410A on-off DM17-01.01.08en
27
Indoor model MCD-36HRN1-R1 MCD-48HRN1-R MCD-60HRN1-R
Outdoor model MOD31U-36HN1-R MOU-48HN1-R MOU
A
-60HN1-R
Power supply V,Hz,Ph 380~415,50,3 380~415,50,3 380~415,50,3
Cooling
Capacity Btu/h 36000 48000 55000
Input W 3600 5191 6272
Current A 6 9.2 11
EER W/W 2,93 2.71 2.57
Heating
Capacity Btu/h 36000 52000 61000
Input W 3650 4763 5843
Current A 6.1 8.5 10.3
COP W/W 2,89 3.2 3.06
Indoor fan
motor
Model YKS-125-6-3 YDK125-6E YDK125-6E
Qty 1 1 1
Input w 174/145/121 209/145/121 209/145/121
Capacitor uF 5UF/450V 5UF/450V 5UF/450V
Speed(hi/mi/lo) r/min 690/610/540 775/610/540 775/610/540
Indoor coil
a.Number of rows 2.0 3 3
b.Tube pitch(a)x row
pitch(b)
mm 21x13.37 21x13.37 21x13.37
c.Fin spacing mm 1.4 1,4 1,4
d.Fin type (code) Hydrophilic aluminium
Hydrophilic
aluminium
Hydrophilic
aluminium
e.Tube outside dia.and
type
mm Φ7,innergroove tube Φ7,innergroove tube
Φ7,innergroove
tube
f.Coil length x height x
width
mm 2010x210x26.74 2080x210x40.11 2080x252x40.11
g.Number of circuits 10 10 12
Indoor air flow (Hi/Med/Lo) m
3
/h 1731/1494/1297 1900/1600/1400 2000/1700/1500
Sound level (sound pressure) dB(A) 51.7/48.0/45.2 53/48/44 53/48/44
Throttle type / / /
Indoor unit
Dimension (W x Dx H)
(body)
mm 840x840x245 840x840x245
840x840x287
Packing (W x Dx
H)(body)
mm 900x900x257 900x900x265
900x900x292
Dimension (W x Dx
H)(panel)
mm 950x950x55 950x950x55 950x950x55
Packing (W x Dx
H)(panel)
mm 1035x1035x90 1035x1035x90 1035x1035x90
Net/Gross weight(body) kg 24.9/28.8 27/32 29/34
Net/Gross weight(panel) kg 5/8 5/8 5/8
Design pressure MPa 4.2/1.5 4.2/1.5 4.2/1.5
Drainage water pipe dia. mm ODΦ32 ODΦ32 ODΦ32
Refrigerant
piping
Liquid side/ Gas side mm Φ9.52/Φ19(3/8"/3/4") Φ12.7/Φ19 Φ12.7/Φ19
Controller RG36C/BG(C)E RG36C/BG(C)E RG36C/BG(C)E
Operation temperature
Ԩ
17~30 17~30 17~30
Room
temperature
Cooling
Ԩ
17～32 17~32 17~32
Heating
Ԩ
0～30 0~30 0~30
Remarks:
1.The above design and specifications are subject to change without prior notice for product improvement.

Midea MCA3-12HRN1-Q1 Specifications

General

Brand	Midea
Model	MCA3-12HRN1-Q1
Category	Air Conditioner
Language	English
