Light Commercial R410A on-off DM17-01.01.08en
47
Indoor model MTI-36HWN1-R1 MTB-48HWN1-R MTB-60HWN1-R
Outdoor model MOD31U-36HN1-R MOU-48HN1-R MOU
-60HN1-R
Power supply V,Hz,Ph 380~415,50,3 380~420,50,3 380~420,50,3
Cooling
Capacity Btu/h 36000 48000 55000
Input W 3654 5240 6225
Current A 6.12 7,60 10,90
EER W/W 2,89 2,68 2,59
Heating
Capacity Btu/h 37000 55000 60000
Input W 3315 4400 5187
Current A 5.64 6,4 9,10
COP W/W 3,27 3,66 3,39
Indoor fan
motor
Model YKSS-115-4-21 YSK180-4P YSK180-4P
Qty 1 1 1
Input W 238/198/167 356/201/152 355/223/173
Capacitor uF 5 10UF/450V 10UF/450V
Speed(Hi/Med/Lo) r/min 860/830/730 1070/750/650 1080/830/710
Indoor coil
Number of rows 3 3 4
Tube pitch(a)*row
pitch(b) mm
21x13.37 21x13.37
21x13.37
Fin spacing mm
1.4 1.3
1,4
Fin type Hydrophilic aluminium Hydrophilic aluminium Hydrophilic aluminium
Tube outside dia.and
type mm
Φ7, innergroove tube Φ7,innergroove tube
Φ7,innergroove tube
Coil length * height *
width mm
915x294x40.11 1030x378x53.48
1030x378x53.48
Number of circuits
7 8
8
Indoor air flow (Hi/Med/Lo) m
/h 1804/1372/1149 2282/1439/- 2275/-/-
ESP
Rated Pa 37 50 50
Range Pa 0-100 0-100 0-120
Indoor noise level (Hi/Med/Lo) dB(A) 48.7/43/40.6 50/45/40 47/40/38
Throttle type / / /
Indoor unit
Dimension (WxDxH) mm 1100x774x249 1200x865x300 1200x865x300
Packing(WxDxH) mm 1305x805x305 1405x920x373 1405x920x373
Net/Gross weight kg 32.2/39.4 44.5/53 47/55
Design pressure MPa 4.2/1.5 4.2/1.5 4.2/1.5
Drainage water pipe diameter mm ODΦ25mm 0DΦ25 0DΦ25
Refrigerant
piping Liquid side/ Gas side mm
Φ9.52/Φ19(3/8"/3/4") Φ12.7/Φ19 Φ12.7/Φ19
Controller KJR-12B/DP(T)-E-2 KJR-12B/DP(T)-E-2 KJR-12B/DP(T)-E-2
Operation temperature
℃ 17~30 17~30 17~30
Room
temperature
Cooling
℃
17～32 17~32 17~32
Heating
℃
0～30 0~30 0~30
