MCAC-VTSM-2013-12 R410a Full DC Inverter Mini VRF
Specifications & Performance 17
4. Piping Diagrams
High pressure
switch
Oil seperator
Oil return
capilary
Compressor
Low pressure
switch
Low pressure
liquid
accumulator can
Condensor
High pressure
liquid
accumulator
can
Electronic
expansion
valve
Electronic
expansion
valve
Evaporator
