Midea MER30B12AWWC

SPECIFICATION
MODEL MER30B12AWWC
120/240V~ 60Hz - 9.65kW
120/208V~ 60Hz - 7.238kW
POWER SUPPLY
PRODUCT DIMENSIONS
A. 25.63” (65.1 cm) depth. Back of range to front of cooktop
B.
C. 46.38” (117.8 cm) overall height (max.) with leveling legs
D. 29.87”(75.9 cm) width
E. 35.9” (91.2 cm) cooktop height (max.) with leveling legs
46.4” (117.9 cm) max. depth. Back of range to the top with the door opened
EN-10
