PRODUCT OVERVIEW
Range Parts Diagram
A. Cooktop Knob
B. Control Panel
C. Cooktop Knob
D. Ceramic Glass Surface
E. Oven Light
F. Oven Racks
G. Gasket
H. Oven Door with Handle
I. Storage Drawer
J. Broiler
K. Oven Vent
L. Adjustable Feet x 4
B
D
F
L
E
H
G
I
C
K
A
J
Rating Plate Label Location:
• The rating plate label contains appliance certification, rating, and
identification information. The model and serial number from the rating
plate label is needed to register the product, order replacement parts, or
when contacting customer service. The rating plate label is located in
the left side of the front frame.
rating label position
RANGE PARTS DIAGRAM:
