step
1. Power off the refrigerator, and remove all objects from door trays.
2. Dismantle the screw hole caps ,screws and handle, and remove the plastic
screw hole caps from the other side.
3. Dismantle the upper hinge cover, screws and upper hinge, and remove the
hole cover from the other side. unplug the wiring connector on the right side
of refrigerator top( , wiring connector).
4. Dismantle the door and right bottom hinge assembly(hinge shaft&adjustable
foot&hinge), disassemble the right bottom hinge assembly,and assemble the
hinge shaft and adjustable foot on the other side of hinge, then assemble the
whole hinge assembly on the other side of refrigerator.
08
hole cover
hinge cover
adjustable foot
hinge shaft
5. Remove the door upper cover, install the upper hinge sleeve , door signal
line to the other side and install the door upper cover.
Remove the stop block and shaft sleeve and install them on the other side of
the door body.
EN
