09
ATTENTION
The picture above is only for reference. The actual configuration will depend on the physical
product or statement by the distributor.
7. For the assembly of handle ,please refer to chapter “Door handle installation”.
hole cover
hinge cover
6. Take out the left top hinge , left top hinge cover from accessories
package,place the door on bottom hinge ,and mount left top hinge.Connect
signal line terminal with signal line terminal , connect signal line terminal 1
with signal line terminal mount top hinge cover and hole cover.
sleeve pipe
door signal line
door upper cover
sleeve pipe
stopper
stopper screw
5)
