Midea MFA-96CRN1 User Manual

R410A 50Hz Tropical Split AC MCAC-UTSM-2012-12
92
1. Specifications
Model
MOV-76CN1-C
MOV-76HN1-C
MOV-96CN1-C
MOV-96HN1-C
Power supply
-
380~415V-3N-50Hz
380~415V-3N-50Hz
Ambient temp range
℃
17~52
-7～52
17~52
-7～52
Rated input
W
11700
11700
14400
14400
Rated current
A
19.3
19.3
23.7
23.7
Noise level
dB(A)
65
65
67
67
Compressor
Type
-
scroll
scroll
scroll
scroll
Brand
-
Copland
Copland
Copland
Copland
Model
-
ZP90KCE-TFD-522
ZP90KCE-TFD-522
ZP120KCE-TFD-522
ZP120KCE-TFD-522
Qty.
-
1
1
1
1
Capacity
Btu/h
74500
74500
100000
100000
Input
W
6950
6950
9110
9110
Rated current
A
12.3
12.3
16.6
16.6
Locked rotor Amp
A
110
110
110
110
Refrigerant
Type
-
R410A
R410A
R410A
R410A
Charge
g
5400
5400
6000
6000
Fan
Type
-
Axial fan
Axial fan
Axial fan
Axial fan
Dimension
mm
Φ530
Φ530
Φ530
Φ530
Drive type
-
Direct
Direct
Direct
Direct
Motor input
W
310+292
310+292
670+644
670+644
Motor speed
rpm
928/942
928/942
1250/1220
1250/1220
Coil
Type
-
Copper tube and aluminum fin
Copper tube and aluminum fin
Tube size
mm
Φ7.94
Φ7.94
Φ7
Φ7
No. of rows
-
2
2
3
3
Fin per inch
FPI
18
18
19
19
Length * height
mm
2185*880
2185*880
2179*882
2179*882
Refrigerant
piping
Liquid side/ Gas side
mm
Φ9.52/Φ22
Φ9.52/Φ22
Φ9.52/Φ25
Φ9.52/Φ25
Max. pipe length
m
50
50
50
50
Max. difference in level
m
30
30
30
30
Connection
wiring
Power wiring
mm
2
5×6.0
5*6.0
5*6.0
5*6.0
Signal wiring
mm
2
2×1.0
4*1.0
2*1.0
4*1.0
Dimension (W*H*D)
mm
1260*908*700
1260*908*700
1260*908*700
1260*908*700
Packing (W*H*D)
mm
1320*1060*730
1320*1060*730
1320*1060*730
1320*1060*730
Net/ Gross weight
kg
171/190
174/193
185/202
187/204
Shipping Qty per 20'/40'/40'HD
pcs
24/54/54
24/54/54
24/54/54
24/54/54
Notes:
1. Nominal cooling capacities are based on the following conditions:
Indoor temp: 27°CDB, 19°CWB; Outdoor temp: 35°CDB; Equivalent refrigerant piping: 7.5m (horizontal)
2. Nominal heating capacities are based on the following conditions:
Indoor temp: 20°CDB; Outdoor temp: 7°CDB, 6°CWB; Equivalent ref. piping: 7.5m (horizontal)

Midea MFA-96CRN1 Specifications

General

Brand	Midea
Model	MFA-96CRN1
Category	Air Conditioner
Language	English
