All indicators shown in the figure are for the purpose of clear presentation. But during the actual
operation, only the relative function signs are shown on the display window.
NOTE
Information are displayed when the remote controller is power up.
AUTO COOL
DRY
HEAT FAN
MODE display
Displays the current mode, including:
Transmission Indicator Lights up
when remote sends signal to
indoor unit
TIMER ON
display
TIMER OFF display
Silence feature display
Breeze Away display
Active clean feature display
Air magic/UV-C lamp feature display
Sleep mode display
Follow me feature display
Wireless control feature display
Low battery detection display(If flashes)
Remote Screen Indicators
Temperature/Timer/Fan speed
ECO display
Displays when ECO feat
ure is
activated
GEAR display
Displays when GEAR feature
is activated
LOCK display
Displays when LOCK feature is
activated.
This display is blank when
operating in FAN mode.
display
Displays the set temperature
by default, or fan speed or
timer setting when using
TIMER ON/OFF functions.
Temperature range:
16-30°C / 60-86°F)
(20-28°C / 68-82°F)
(Model dependent)
Timer setting range:
0-24 hours
Fan speed setting range:
AU -100%
FAN SPEED display
Displays selected fan speed:
Silence
LOW
MED
HIGH
AUTO
2%-20%
21%-40%
41%-60%
61%-80%
81%-100%
1%
This fan speed can not be
adjusted in AUTO or DRY
mode.
Horizontal louver
swing display
Vertical louver
auto swing display
Boost mode display
Not available for
this unit
 

 
