MCAC-2008-11 Air-cooled Modular Chiller
69
At this page, you could select Operation Mode and Control Mode, adjust temperature and set Power Failure
Memory.
Temperature setting range: Cooling 7 ~12 , Heating 45 ~50 . ℃℃ ℃℃
Malfunction queried window:
Press “Check Error” button at Query window or press “Check Error record” in principal window accessing to
following window:
Malfunction occurring time and detail contents could be queried in this page. Click the malfunction in the
form, and then click “Help” button, simple troubleshoot methods will be showed for user reference.
Error history window
In the page 1 of error history window, click “Check history record” button get in following window:
In this page, the ever occurred malfunctions and occurring times would be showed, however, once power
failure, the malfunctions records would vanish.
Weekly timer setting window:
In this page, click “Weekly timer set” enters into following window:
To Next Page
