Midea MGB-D65W/RN1

Air-cooled modular chiller unit 50Hz MCAC-ATSM-2011-12
34
65KW digital module refrigeration system sketch drawing (MGB-D65W/RN1)
Each module has three compressors with two separate units, one shell and tube evaporator for two systems.
5.3 130KW module refrigeration system sketch drawing
Each module has four compressors with two separate units, one shell and tube evaporator for four systems
Dry type evaporator
Condenser
Water flow direction
Compressor B
low pressure cylinder B
4-Way valve A
Fan A
EXV
Capillary
EXV
2-1/2"
Unit 2
Capillary
Fan B
4-Way valve B
Compressor A
low pressure cylinder A
Unit 1
Dry type evaporator
Condenser
Water flow direction
Compressor B
low pressure cylinder B
4-Way valve A
Fan A
EXV
Capillary
EXV
Capillary
Fan B
4-Way valve B
Com. A1
digital
low pressure cylinder A
Pressure switch
Pressure switch
Pressure switch
Pressure switch
Discharge switch
Pressure switch
Pressure switch
T3B
T3A
Discharge switch
Com. A2
